ML Metadata

ML Metadata (MLMD) is a library for recording and retrieving metadata associated with ML developer and data scientist workflows. MLMD is an integral part of TensorFlow Extended (TFX), but is designed so that it can be used independently.

Every run of a production ML pipeline generates metadata containing information about the various pipeline components, their executions (e.g. training runs), and resulting artifacts (e.g. trained models). In the event of unexpected pipeline behavior or errors, this metadata can be leveraged to analyze the lineage of pipeline components and debug issues. Think of this metadata as the equivalent of logging in software development.

MLMD helps you understand and analyze all the interconnected parts of your ML pipeline instead of analyzing them in isolation and can help you answer questions about your ML pipeline such as:

  • Which dataset did the model train on?
  • What were the hyperparameters used to train the model?
  • Which pipeline run created the model?
  • Which training run led to this model?
  • Which version of TensorFlow created this model?
  • When was the failed model pushed?

Metadata store

MLMD registers the following types of metadata in a database called the Metadata Store.

  1. Metadata about the artifacts generated through the components/steps of your ML pipelines
  2. Metadata about the executions of these components/steps
  3. Metadata about pipelines and associated lineage information

The Metadata Store provides APIs to record and retrieve metadata to and from the storage backend. The storage backend is pluggable and can be extended. MLMD provides reference implementations for SQLite (which supports in-memory and disk) and MySQL out of the box.

This graphic shows a high-level overview of the various components that are part of MLMD.

ML Metadata Overview

Metadata storage backends and store connection configuration

The MetadataStore object receives a connection configuration that corresponds to the storage backend used.

  • Fake Database provides an in-memory DB (using SQLite) for fast experimentation and local runs. The database is deleted when the store object is destroyed.
import ml_metadata as mlmd
from ml_metadata.metadata_store import metadata_store
from ml_metadata.proto import metadata_store_pb2

connection_config = metadata_store_pb2.ConnectionConfig()
connection_config.fake_database.SetInParent() # Sets an empty fake database proto.
store = metadata_store.MetadataStore(connection_config)
  • SQLite reads and writes files from disk.
connection_config = metadata_store_pb2.ConnectionConfig()
connection_config.sqlite.filename_uri = '...'
connection_config.sqlite.connection_mode = 3 # READWRITE_OPENCREATE
store = metadata_store.MetadataStore(connection_config)
  • MySQL connects to a MySQL server.
connection_config = metadata_store_pb2.ConnectionConfig()
connection_config.mysql.host = '...'
connection_config.mysql.port = '...'
connection_config.mysql.database = '...'
connection_config.mysql.user = '...'
connection_config.mysql.password = '...'
store = metadata_store.MetadataStore(connection_config)

Similarly, when using a MySQL instance with Google CloudSQL (quickstart, connect-overview), one could also use SSL option if applicable.

connection_config.mysql.ssl_options.key = '...'
connection_config.mysql.ssl_options.cert = '...'
connection_config.mysql.ssl_options.ca = '...'
connection_config.mysql.ssl_options.capath = '...'
connection_config.mysql.ssl_options.cipher = '...'
connection_config.mysql.ssl_options.verify_server_cert = '...'
store = metadata_store.MetadataStore(connection_config)
  • PostgreSQL connects to a PostgreSQL server.
connection_config = metadata_store_pb2.ConnectionConfig()
connection_config.postgresql.host = '...'
connection_config.postgresql.port = '...'
connection_config.postgresql.user = '...'
connection_config.postgresql.password = '...'
connection_config.postgresql.dbname = '...'
store = metadata_store.MetadataStore(connection_config)

Similarly, when using a PostgreSQL instance with Google CloudSQL (quickstart, connect-overview), one could also use SSL option if applicable.

connection_config.postgresql.ssloption.sslmode = '...' # disable, allow, verify-ca, verify-full, etc.
connection_config.postgresql.ssloption.sslcert = '...'
connection_config.postgresql.ssloption.sslkey = '...'
connection_config.postgresql.ssloption.sslpassword = '...'
connection_config.postgresql.ssloption.sslrootcert = '...'
store = metadata_store.MetadataStore(connection_config)

Data model

The Metadata Store uses the following data model to record and retrieve metadata from the storage backend.

  • ArtifactType describes an artifact's type and its properties that are stored in the metadata store. You can register these types on-the-fly with the metadata store in code, or you can load them in the store from a serialized format. Once you register a type, its definition is available throughout the lifetime of the store.
  • An Artifact describes a specific instance of an ArtifactType, and its properties that are written to the metadata store.
  • An ExecutionType describes a type of component or step in a workflow, and its runtime parameters.
  • An Execution is a record of a component run or a step in an ML workflow and the runtime parameters. An execution can be thought of as an instance of an ExecutionType. Executions are recorded when you run an ML pipeline or step.
  • An Event is a record of the relationship between artifacts and executions. When an execution happens, events record every artifact that was used by the execution, and every artifact that was produced. These records allow for lineage tracking throughout a workflow. By looking at all events, MLMD knows what executions happened and what artifacts were created as a result. MLMD can then recurse back from any artifact to all of its upstream inputs.
  • A ContextType describes a type of conceptual group of artifacts and executions in a workflow, and its structural properties. For example: projects, pipeline runs, experiments, owners etc.
  • A Context is an instance of a ContextType. It captures the shared information within the group. For example: project name, changelist commit id, experiment annotations etc. It has a user-defined unique name within its ContextType.
  • An Attribution is a record of the relationship between artifacts and contexts.
  • An Association is a record of the relationship between executions and contexts.

MLMD Functionality

Tracking the inputs and outputs of all components/steps in an ML workflow and their lineage allows ML platforms to enable several important features. The following list provides a non-exhaustive overview of some of the major benefits.

  • List all Artifacts of a specific type. Example: all Models that have been trained.
  • Load two Artifacts of the same type for comparison. Example: compare results from two experiments.
  • Show a DAG of all related executions and their input and output artifacts of a context. Example: visualize the workflow of an experiment for debugging and discovery.
  • Recurse back through all events to see how an artifact was created. Examples: see what data went into a model; enforce data retention plans.
  • Identify all artifacts that were created using a given artifact. Examples: see all Models trained from a specific dataset; mark models based upon bad data.
  • Determine if an execution has been run on the same inputs before. Example: determine whether a component/step has already completed the same work and the previous output can just be reused.
  • Record and query context of workflow runs. Examples: track the owner and changelist used for a workflow run; group the lineage by experiments; manage artifacts by projects.
  • Declarative nodes filtering capabilities on properties and 1-hop neighborhood nodes. Examples: look for artifacts of a type and under some pipeline context; return typed artifacts where a given property’s value is within a range; find previous executions in a context with the same inputs.

See the MLMD tutorial for an example that shows you how to use the MLMD API and the metadata store to retrieve lineage information.

Integrate ML Metadata into your ML Workflows

If you are a platform developer interested in integrating MLMD into your system, use the example workflow below to use the low-level MLMD APIs to track the execution of a training task. You can also use higher-level Python APIs in notebook environments to record experiment metadata.

ML Metadata Example Flow

1) Register artifact types

# Create ArtifactTypes, e.g., Data and Model
data_type = metadata_store_pb2.ArtifactType()
data_type.name = "DataSet"
data_type.properties["day"] = metadata_store_pb2.INT
data_type.properties["split"] = metadata_store_pb2.STRING
data_type_id = store.put_artifact_type(data_type)

model_type = metadata_store_pb2.ArtifactType()
model_type.name = "SavedModel"
model_type.properties["version"] = metadata_store_pb2.INT
model_type.properties["name"] = metadata_store_pb2.STRING
model_type_id = store.put_artifact_type(model_type)

# Query all registered Artifact types.
artifact_types = store.get_artifact_types()

2) Register execution types for all steps in the ML workflow

# Create an ExecutionType, e.g., Trainer
trainer_type = metadata_store_pb2.ExecutionType()
trainer_type.name = "Trainer"
trainer_type.properties["state"] = metadata_store_pb2.STRING
trainer_type_id = store.put_execution_type(trainer_type)

# Query a registered Execution type with the returned id
[registered_type] = store.get_execution_types_by_id([trainer_type_id])

3) Create an artifact of DataSet ArtifactType

# Create an input artifact of type DataSet
data_artifact = metadata_store_pb2.Artifact()
data_artifact.uri = 'path/to/data'
data_artifact.properties["day"].int_value = 1
data_artifact.properties["split"].string_value = 'train'
data_artifact.type_id = data_type_id
[data_artifact_id] = store.put_artifacts([data_artifact])

# Query all registered Artifacts
artifacts = store.get_artifacts()

# Plus, there are many ways to query the same Artifact
[stored_data_artifact] = store.get_artifacts_by_id([data_artifact_id])
artifacts_with_uri = store.get_artifacts_by_uri(data_artifact.uri)
artifacts_with_conditions = store.get_artifacts(
      list_options=mlmd.ListOptions(
          filter_query='uri LIKE "%/data" AND properties.day.int_value > 0'))

4) Create an execution of the Trainer run

# Register the Execution of a Trainer run
trainer_run = metadata_store_pb2.Execution()
trainer_run.type_id = trainer_type_id
trainer_run.properties["state"].string_value = "RUNNING"
[run_id] = store.put_executions([trainer_run])

# Query all registered Execution
executions = store.get_executions_by_id([run_id])
# Similarly, the same execution can be queried with conditions.
executions_with_conditions = store.get_executions(
    list_options = mlmd.ListOptions(
        filter_query='type = "Trainer" AND properties.state.string_value IS NOT NULL'))

5) Define the input event and read data

# Define the input event
input_event = metadata_store_pb2.Event()
input_event.artifact_id = data_artifact_id
input_event.execution_id = run_id
input_event.type = metadata_store_pb2.Event.DECLARED_INPUT

# Record the input event in the metadata store
store.put_events([input_event])

6) Declare the output artifact

# Declare the output artifact of type SavedModel
model_artifact = metadata_store_pb2.Artifact()
model_artifact.uri = 'path/to/model/file'
model_artifact.properties["version"].int_value = 1
model_artifact.properties["name"].string_value = 'MNIST-v1'
model_artifact.type_id = model_type_id
[model_artifact_id] = store.put_artifacts([model_artifact])

7) Record the output event

# Declare the output event
output_event = metadata_store_pb2.Event()
output_event.artifact_id = model_artifact_id
output_event.execution_id = run_id
output_event.type = metadata_store_pb2.Event.DECLARED_OUTPUT

# Submit output event to the Metadata Store
store.put_events([output_event])

8) Mark the execution as completed

trainer_run.id = run_id
trainer_run.properties["state"].string_value = "COMPLETED"
store.put_executions([trainer_run])

9) Group artifacts and executions under a context using attributions and assertions artifacts

# Create a ContextType, e.g., Experiment with a note property
experiment_type = metadata_store_pb2.ContextType()
experiment_type.name = "Experiment"
experiment_type.properties["note"] = metadata_store_pb2.STRING
experiment_type_id = store.put_context_type(experiment_type)

# Group the model and the trainer run to an experiment.
my_experiment = metadata_store_pb2.Context()
my_experiment.type_id = experiment_type_id
# Give the experiment a name
my_experiment.name = "exp1"
my_experiment.properties["note"].string_value = "My first experiment."
[experiment_id] = store.put_contexts([my_experiment])

attribution = metadata_store_pb2.Attribution()
attribution.artifact_id = model_artifact_id
attribution.context_id = experiment_id

association = metadata_store_pb2.Association()
association.execution_id = run_id
association.context_id = experiment_id

store.put_attributions_and_associations([attribution], [association])

# Query the Artifacts and Executions that are linked to the Context.
experiment_artifacts = store.get_artifacts_by_context(experiment_id)
experiment_executions = store.get_executions_by_context(experiment_id)

# You can also use neighborhood queries to fetch these artifacts and executions
# with conditions.
experiment_artifacts_with_conditions = store.get_artifacts(
    list_options = mlmd.ListOptions(
        filter_query=('contexts_a.type = "Experiment" AND contexts_a.name = "exp1"')))
experiment_executions_with_conditions = store.get_executions(
    list_options = mlmd.ListOptions(
        filter_query=('contexts_a.id = {}'.format(experiment_id))))

Use MLMD with a remote gRPC server

You can use MLMD with remote gRPC servers as shown below:

  • Start a server
bazel run -c opt --define grpc_no_ares=true  //ml_metadata/metadata_store:metadata_store_server

By default, the server uses a fake in-memory db per request and does not persist the metadata across calls. It can also be configured with a MLMD MetadataStoreServerConfig to use SQLite files or MySQL instances. The config can be stored in a text protobuf file and passed to the binary with --metadata_store_server_config_file=path_to_the_config_file.

An example MetadataStoreServerConfig file in text protobuf format:

connection_config {
  sqlite {
    filename_uri: '/tmp/test_db'
    connection_mode: READWRITE_OPENCREATE
  }
}
  • Create the client stub and use it in Python
from grpc import insecure_channel
from ml_metadata.proto import metadata_store_pb2
from ml_metadata.proto import metadata_store_service_pb2
from ml_metadata.proto import metadata_store_service_pb2_grpc

channel = insecure_channel('localhost:8080')
stub = metadata_store_service_pb2_grpc.MetadataStoreServiceStub(channel)
  • Use MLMD with RPC calls
# Create ArtifactTypes, e.g., Data and Model
data_type = metadata_store_pb2.ArtifactType()
data_type.name = "DataSet"
data_type.properties["day"] = metadata_store_pb2.INT
data_type.properties["split"] = metadata_store_pb2.STRING

request = metadata_store_service_pb2.PutArtifactTypeRequest()
request.all_fields_match = True
request.artifact_type.CopyFrom(data_type)
stub.PutArtifactType(request)

model_type = metadata_store_pb2.ArtifactType()
model_type.name = "SavedModel"
model_type.properties["version"] = metadata_store_pb2.INT
model_type.properties["name"] = metadata_store_pb2.STRING

request.artifact_type.CopyFrom(model_type)
stub.PutArtifactType(request)

Resources

The MLMD library has a high-level API that you can readily use with your ML pipelines. See the MLMD API documentation for more details.

Check out MLMD Declarative Nodes Filtering to learn how to use MLMD declarative nodes filtering capabilities on properties and 1-hop neighborhood nodes.

Also check out the MLMD tutorial to learn how to use MLMD to trace the lineage of your pipeline components.

MLMD provides utilities to handle schema and data migrations across releases. See the MLMD Guide for more details.
